316 Round Bar: The Corrosion-Resistant, High-Performance Industrial Choice
Stainless steel products

316 Round Bar: The Corrosion-Resistant, High-Performance Industrial Choice

Precise size and smooth surface, suitable for industrial and decorative fields with strict requirements on precision and appearance.

Standard: ASTM A276 ASTM A564
Grade: 304 316 321 904l 630
Surface: Black Bright Grinding
Diameter: 1mm to 500mm

    Overview

    316 stainless steel is an austenitic stainless steel alloy that is widely used in various applications due to its excellent corrosion resistance, good mechanical properties and high temperature resistance. 316 stainless steel round bar is a common product made from this alloy. Stainless steel round bar (rough round) can be applied to: metal products, rail transportation, nuclear power, machinery manufacturing, chemical equipment, pressure vessels.

    Customized Stainless steelstainless_round_bar

    Features

    ● The surface quality of the round bar material is good (no cracks, no pitting).

    ● Corrosion resistance: 316 stainless steel round bar has excellent corrosion and oxidation resistance in various environments, including chemical, marine and industrial environments.

    ● High strength: 316 stainless steel round bar has high strength and toughness, making it suitable for applications that require high strength and durability.

    ● Easy to process: 316 stainless steel round bar can be easily processed using conventional methods, making it suitable for various manufacturing processes. The product specification range is large, the round bar has high roundness, high straightness, small tolerance and high dimensional accuracy (grinding rod can reach 0.01mm).

    ● Good welding and forming properties: 316 stainless steel round bar has good welding and forming properties, making it easy to process and suitable for a wide range of applications.

    ● High temperature resistance: 316 stainless steel round bar can withstand temperatures up to 870°C (1600°F) without losing its properties, making it an ideal choice for high temperature applications.

    ● Hygienic: 316 stainless steel round bar is hygienic and easy to clean, making it suitable for use in the food and beverage industry, medical equipment, and other applications where cleanliness is critical.

    Stainless steel round 5Stainless steel round 4

    Standard Stainless Steel Rod Sizes

    Type SIZES in milimeter SIZES in inches Tolerance
    Peeled and Polished 40.00-150.00 1.50-6.00 h11,h11-DIN 1013
    Cold Drawn and Polish 3.00 to 75.00 1/8 to3.00 h8 to h11
    Cold Drawn and Ground 10.00 to 75.00 5/6 to 2.50 h8 to h11
    Peeled nd Ground 20.00-50.00 3/4-2.00 h9 to h11


    Specifications of 316 stainless steel bar:

    Standard ASTM A276, A484, A479, A580, A582, JIS G4303, JIS G4311,DIN 1654-5,DIN 17440,KS D3706,GB/T 1220
    Material 201,202,205,XM-19 etc.
    301,303,304,304L,304H,309S,310S,314,316,316L,316Ti,317,321,321H,329,330,348 etc.
    409,410,416,420,430,430F,431,440
    2205,2507,S31803,2209,630,631,15-5PH,17-4PH,17-7PH,904L,F51,F55,253MA etc.
    Surface Bright,Polishing,Pickled,Peeled,Black,Grinding etc
    Technology Cold Drawn,Hot Rolled,Forged
    Specifications Diameter : 2 4 5 6 7 8 9 20 24 25 40mm or as your required,Length:5.8m,6m or as required
    Tolerance H9, H11, H13, K9, K11, K13 or as required

    Stainless Steel 316/316L/316H/316Ti bar Equivalent Grades:
    STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
    SS 316 1.4401 / 1.4436 S31600 SUS 316 316S31 / 316S33 - Z7CND17‐11‐02 X5CrNiMo17-12-2 / X3CrNiMo17-13-3
    SS 316L 1.4404 / 1.4435 S31603 SUS 316L 316S11 / 316S13 03Ch17N14M3 / 03Ch17N14M2 Z3CND17‐11‐02 / Z3CND18‐14‐03 X2CrNiMo17-12-2 / X2CrNiMo18-14-3
    SS 316H 1.4401 S31609 SUS 316H - - - -
    SS 316Ti 1.4571 S31635 SUS 316Ti 320S31 08Ch17N13M2T Z6CNDT17‐123 X6CrNiMoTi17-12-2



    SS 316/316L/316H/316Ti bar Chemical Composition and Mechanical properties:

    Grade C Mn Si P S Cr Mo Ni N
    SS 316 0.08 max 2.0 max 1.0 max 0.045 max 0.030 max 16.00 – 18.00 2.00 – 3.00 11.00 – 14.00 67.845 min
    SS 316L 0.035 max 2.0 max 1.0 max 0.045 max 0.030 max 16.00 – 18.00 2.00 – 3.00 10.00 – 14.00 68.89 min
    SS 316H 0.10 max 2.0 max 0.75 max 0.045 max 0.030 max 16.00 – 18.00 2.00 – 3.00 10.00 – 14.00 68.89 min
    SS 316Ti 0.08 max 2.0 max 0.75 max 0.045 max 0.030 max 16.00 – 18.00 2.00 – 3.00 10.00 – 14.00 68.395 min



    Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
    8.0 g/cm3 1400 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35%


    Avilable Stock of 316 stainless steel bar :

     Grade  Type  Surface  Diameter(mm) Length(mm)
     316L  Round  bright  6-40 6000
     316Lo1   Round  bright  6-40 6000
     316F   Round  bright  6-40 6000
     316L   Round  black 65/75/90/105/125/130 6000
     316L   Round  black  70/80/100/110/120 6000
     316L   Round  black 85/95/115 6000
     316L   Round  black  150 6000
     316L   Round  black 160/180/200/240/250 6000
     316L   Round  black 300/350 6000
    316L  Round black 400/450/500/600 6000



    SAKY STEEL’S Quality Assurance (including both Destructive and Non-Destructive) :

    1. Visual Dimension Test
    2. Mechanical examining like tensile, Elongation and reduction of area.
    3. Ultrasonic test
    4. Chemical examination analysis
    5. Hardness test
    6. Pitting protection test
    7. Penetrant Test
    8. Intergranular Corrosion Testing
    9. Impact analysis
    10. Metallography Experimental Test
