Marine Grade Corrosion Resistant | High-Performance Industrial Material
Overview
304 stainless steel is an austenitic stainless steel alloy that is widely used in various applications due to its excellent corrosion resistance, good mechanical properties and high temperature resistance. 304 stainless steel round bar is a common product made from this alloy. Stainless steel round bar (rough round) can be applied to: metal products, rail transportation, nuclear power, machinery manufacturing, chemical equipment, pressure vessels.
Features
● The surface quality of the round bar material is good (no cracks, no pitting).
● Corrosion resistance: 304 stainless steel round bar has excellent corrosion and oxidation resistance in various environments, including chemical, marine and industrial environments.
● High strength: 304 stainless steel round bar has high strength and toughness, making it suitable for applications that require high strength and durability.
● Easy to process: 304 stainless steel round bar can be easily processed using conventional methods, making it suitable for various manufacturing processes. The product specification range is large, the round bar has high roundness, high straightness, small tolerance and high dimensional accuracy (grinding rod can reach 0.01mm).
● Good welding and forming properties: 304 stainless steel round bar has good welding and forming properties, making it easy to process and suitable for a wide range of applications.
● High temperature resistance: 304 stainless steel round bar can withstand temperatures up to 870°C (1600°F) without losing its properties, making it an ideal choice for high temperature applications.
● Hygienic: 304 stainless steel round bar is hygienic and easy to clean, making it suitable for use in the food and beverage industry, medical equipment, and other applications where cleanliness is critical.
| Type | SIZES in milimeter | SIZES in inches | Tolerance |
| Peeled and Polished | 40.00-150.00 | 1.50-6.00 | h11,h11-DIN 1013 |
| Cold Drawn and Polish | 3.00 to 75.00 | 1/8 to3.00 | h8 to h11 |
| Cold Drawn and Ground | 10.00 to 75.00 | 5/6 to 2.50 | h8 to h11 |
| Peeled nd Ground | 20.00-50.00 | 3/4-2.00 | h9 to h11 |
Specifications of 316 stainless steel bar:
| Standard | ASTM A276, A484, A479, A580, A582, JIS G4303, JIS G4311,DIN 1654-5,DIN 17440,KS D3706,GB/T 1220 | |||||||||||
| Material | 201,202,205,XM-19 etc. 301,303,304,304L,304H,309S,310S,314,316,316L,316Ti,317,321,321H,329,330,348 etc. 409,410,416,420,430,430F,431,440 2205,2507,S31803,2209,630,631,15-5PH,17-4PH,17-7PH,904L,F51,F55,253MA etc. |
|||||||||||
| Surface | Bright,Polishing,Pickled,Peeled,Black,Grinding etc | |||||||||||
| Technology | Cold Drawn,Hot Rolled,Forged | |||||||||||
| Specifications | Diameter : 2 4 5 6 7 8 9 20 24 25 40mm or as your required,Length:5.8m,6m or as required | |||||||||||
| Tolerance | H9, H11, H13, K9, K11, K13 or as required | |||||||||||
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | - | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
| SS 316H | 1.4401 | S31609 | SUS 316H | - | - | - | - |
| SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
SS 316/316L/316H/316Ti bar Chemical Composition and Mechanical properties:
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
| SS 316H | 0.10 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
| SS 316Ti | 0.08 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35% |
Avilable Stock of 316 stainless steel bar :
| Grade | Type | Surface | Diameter(mm) | Length(mm) |
| 316L | Round | bright | 6-40 | 6000 |
| 316Lo1 | Round | bright | 6-40 | 6000 |
| 316F | Round | bright | 6-40 | 6000 |
| 316L | Round | black | 65/75/90/105/125/130 | 6000 |
| 316L | Round | black | 70/80/100/110/120 | 6000 |
| 316L | Round | black | 85/95/115 | 6000 |
| 316L | Round | black | 150 | 6000 |
| 316L | Round | black | 160/180/200/240/250 | 6000 |
| 316L | Round | black | 300/350 | 6000 |
| 316L | Round | black | 400/450/500/600 | 6000 |
SAKY STEEL’S Quality Assurance (including both Destructive and Non-Destructive) :
1. Visual Dimension Test
2. Mechanical examining like tensile, Elongation and reduction of area.
3. Ultrasonic test
4. Chemical examination analysis
5. Hardness test
6. Pitting protection test
7. Penetrant Test
8. Intergranular Corrosion Testing
9. Impact analysis
10. Metallography Experimental Test
